What Spec Is Your Engine?


  • Please log in to reply
197 replies to this topic

#31 Oldskoolbaby

Oldskoolbaby

    One Carb Or Two?

  • Members
  • PipPipPipPipPipPipPip
  • 1,361 posts

Posted 24 May 2005 - 05:25 PM

Block
1275 A-Seires 11 stud (pre A-plus) Bored out to 74mm (1400)
Centre mainstrap fitted
Wedged, bladed, cross drilled, back drilled, hardened and balanced 1275 crank
Lightened, polished, shotpeened and balanced rods(Awiating Cooper S rods)
Modified 74mm AE pistons
Water pump inlet opened up
Cooper S Full race cylinder head modified with 38/29mm waisted race valves
Fully ported and only polished on the exhausts
Kent 286 camshaft
Duplex Timing chain

Capable of 8750rpm

HIF 44 SU with K&N airfilter.
Water cooled ally inlet manifold matched to the head
This will change to twin HIF 44 Sus when its run in and on N2O

Largebore LCB fitted to full stainless RC40

Gearbox
A plus casing fitted with a straight cut close ratio gear set(Abingdon ratios)
Staight cut drop gears
4 pin diff with 3.65 final drive
Ultralite flywheel
Padle clutch
Quick shift

Once dynod im looking at 140 bhp with N2o at 8000rpm.

#32 AlexF2003

AlexF2003

    Ring Runner 2005

  • Members
  • PipPipPipPipPip
  • 383 posts

Posted 24 May 2005 - 09:27 PM

170bhp turbo

erm lots of mods!

SRE built 1293cc, Turbo block, balanced and nitro-caburised crack, centre main strap, ARP rod bolts, shot- peened and balanced turbo rods, forged omega pistons with 15cc dish, MED/piper T3 cam, Duplex gears, SRE head, fully worked, 36x31 SS SRE race valves, 8.2:1 CR, Turbo technics recondition T3 with 360 degree thrust bearing, 2stage boost with new solenoid, 2 maniflow down pipe with lambda sensor for A/F ratio meter and custom maniflow exhaust.
Tran-x SC drops, rebuilt cooper box, 5/16th mounting holes, Green air filter, dump valve, Maestro plenium, intercooler and samco hoses, 2core rad.

Alex

#33 marksmini

marksmini

    Mark - Founder of TMF since 2003 - Onwards

  • Admin
  • PipPipPipPipPipPipPipPipPipPipPip
  • 29,297 posts
  • Location: Nottingham
  • Local Club: TMF

Posted 24 May 2005 - 09:36 PM

1982 mini city

998cc
pipe across filter and trumpet
sport x inlet manfold
3 branch (lsd or something like that) exhaust manfold
2inch stright through pipe
sport x back box center exit
carb needle
lightend flywheel
upgrated HT leads
up rated coil
up rated ault
metro head with bypass hose taped in

most my money has gone into other parts of the car
engine is the last thing to do on my mini.

but it will always be a 998cc, but lots of engine work one day soon i hope

#34 Turbo Phil

Turbo Phil

    Camshaft & Stage Two Head

  • TMF+ Member
  • PipPipPipPipPipPipPipPip
  • 1,931 posts
  • Location: Cumbria
  • Local Club: Cumbria Classic Mini Club

Posted 24 May 2005 - 09:52 PM

1293cc Turbo - Metro Turbo block modified to group "A" spec,Hardened crankshaft balanced+wedged,"Carrillo" forged steel con rods,Mahle low compression 15cc forged pistons,4 bolt billet centre main strap,undercrown oil cooling jets, group "A" head gasket,K+N air filter,custom alloy intercooler,Samco hoses,1.5 ratio roller rockers,Group "A" spec gas flowed big valve cylinder head,ARP head studs {11},special cam profile,belt drive cam kit,lightened steel flywheel + backplate,grey clutch diaphram, AP Rally/Race plate,Cooper 's' crank damper,alloy dump valve,billet actuator,Maniflow dowpipe into stainless system,Aldon dizzy, T2 Turbo on modified manifold.
Boost adjustable 8-20psi.
TRANSMISSION-
Jack Knight 4 speed straight cut box,straight cut drop gears,Tran-x limited slip diff,semi helical cw + pinion {3.44},KAD quickshift, uprated driveshafts.

Phil. ;)

#35 neil_g

neil_g

    One Carb Or Two?

  • Members
  • PipPipPipPipPipPipPip
  • 880 posts

Posted 25 May 2005 - 08:10 AM

A+ 1380cc, Omega Cast Pistons, Kent MD286 Camshaft, Ni Tempered and reground Crank, Lightened Flywheel, Stage 3 Head (Valve sizes 35.7 / 30), 1.5 Roller Tip Rockers, HIF44 Carb, Maniflow LCB + Superflow exhaust, Aldon Yellow Distributor, Aldon flamethrower Coil + Ignitor Elec. Ignition, Jack Knight S/C C/R Gearbox, S/C drop gears 1:1 ratio, Semi Helical Crown wheel and Pinion 3.44 ratio, Crosspin Diff, Turbo Clutch.

I've got 2 RR results, first being at Aldon where it got 81bhp/5870RPM @ wheels, second was at Richard Longmans following a timing tweak it made 89bhp/?RPM @ wheels (sorry can't be more specific, I'll dig the sheet out later).

Hopefully squeezing a couple extra ponies by dropping the mechanical fan and water pump.

#36 Pooky

Pooky

    Crazy About Mini's

  • TMF+ Member
  • PipPipPipPipPipPipPipPipPipPip
  • 5,691 posts
  • Location: Sunny Sussex

Posted 27 June 2005 - 10:04 PM

998 A+ with Full Maniflow Stage 1 kit

Cooper Freeflow exhaust manifold (sprayed red!)
Alloy inlet manifold
Single box centre exit pipe
Cone air filter
AAU Needle

Rolling roaded to 55ish BHP at the fly!


Plans to get a lighter flywheel!

#37 nag1_uk

nag1_uk

    Ring Runner 2005

  • Members
  • PipPipPipPip
  • 227 posts

Posted 28 June 2005 - 11:00 AM

1400 mpi K series from 03 reg rover 25 new piper cross filter

#38 gsms

gsms

    Up Into Fourth

  • Members
  • PipPipPipPipPipPipPipPipPip
  • 2,285 posts
  • Location: Sevenoaks, Kent

Posted 28 June 2005 - 07:07 PM

1275cc injection...that's it...

#39 blue racing clubman

blue racing clubman

    Learner Driver

  • Noobies
  • PipPip
  • 22 posts

Posted 28 June 2005 - 08:40 PM

1398cc mini sport block
vmax cylinder head
1.5.1 roller rockers
45 weber,100 mill ram pipes,
av racing clutch
sc/cr straight drops dogbox
aldon yellow dizzy
ignitor electronic ignition,
lucas gold coil
13 row oil cooler,
ss/carbon fibre play mini , w exhast wrap at manifold,


120hp at flywheel
103hp at wheels at6000rpm

#40 themanlegend

themanlegend

    Mini Mad

  • Members
  • PipPipPipPip
  • 244 posts

Posted 11 July 2005 - 12:05 PM

just a 998 stage one , boo hoo

#41 mambaman

mambaman

    Mini Mad

  • Members
  • PipPipPipPip
  • 162 posts

Posted 13 July 2005 - 10:34 AM

88mg metro engine stripped and wearables replaced (shells/rings etc)

std mg metro head - unmodified
recon'd bottom end still 1275
1.3:1 rollers
276cam
std metro transmission

82bhp at the fly
60ish at the wheels.


im building something quiet different though

73.5mm bore - destroked unit 1290cc
sw10cam
custom head with 36/30valves
s/c box
s/c drops
3.6 cwp on a x-pin diff

#42 Jordie

Jordie

    Traders Area Specialist Mod, North and Scotland Area Manager

  • TMF Team
  • PipPipPipPipPipPipPipPipPipPipPip
  • 13,544 posts
  • Name: Jordan
  • Location: North East

Posted 13 July 2005 - 11:14 AM

'A' 998 cc
Customized stage 1 kit - Centre exit box, straight pipe, Y-Piece, Freeflow manifold, MiniSpares Inlet.
1.5" HS4 carb
PiperX Cone Filter

#43 Prawn

Prawn

    One Carb Or Two?

  • Members
  • PipPipPipPipPipPipPip
  • 938 posts
  • Local Club: Basingstoke Mini Club

Posted 13 July 2005 - 04:25 PM

1380 A+ block-centre main strap
73.5mm powermax pistons
lightened polished S rods
hardened wedged X-drilled S crank
MSPD trackday (290) cam
minispares 1.5:1 roller tip rockers
Stage 3 (37x29) unleaded head
turbo oil pump
MSPD billet steel flywheel, lighened backplate and Race/Rally clutch plate
JKD sc drops
JKD sccr box
JKD X-pin diff (3.44fd)

#44 benjamin

benjamin

    Passed Test

  • Noobies
  • PipPip
  • 28 posts

Posted 14 July 2005 - 10:27 AM

1098 block bored too 1144cc
LCB extractors
1 3/4 twin box RC40
metro turbo inlet manifold
1 3/4 hiff44 turbo carb
ram-flo filter
12g202 stock head
pulsar electronic dissy and coil
rod change box with pot joints

#45 TNT

TNT

    Mini Mad

  • Members
  • PipPipPipPip
  • 297 posts
  • Local Club: TMF of course

Posted 17 July 2005 - 04:01 PM

998cc with 'mega-flow' manifold and 'carbon can co' exhaust
